Injector Jet Kit 571 suit 165D

The Davey Injector Jet Kit 571 (Product Code: 22571) is a specific deep-well conversion kit for the Davey 165D pump, designed for use in bores with a minimum internal diameter of 5 inches (125mm) and a depth rating of up to 21 metres.

Key Features and Function

The kit converts the standard centrifugal pump into a jet-assisted system, enabling it to overcome the natural suction lift limits and draw water from deeper sources for applications such as garden sprinklers, tank filling, and stock watering.

Deep Well Performance: This specific 571 injector is rated to effectively draw water from depths down to 21 metres.

• Optimal Flow: With the 571 injector installed, the 165D pump system can achieve a high maximum flow rate of up to 122 litres per minute (lpm), depending on the specific depth and operating conditions.
• Bore Compatibility: The kit is specifically sized for bores with a minimum internal diameter of 5 inches (125mm).
• Durability: The associated Davey 165D pump body is made from marine-grade aluminium with a Rilsan® lining, providing excellent resistance to aggressive water and corrosion.

Components

• A complete deep well injector kit (Product Code: 22571) includes all necessary items for installation in a bore:
• A bronze injector and foot valve assembly, which are the parts submerged in the water.
• An adaptor flange (or bend) to connect the two suction pipes to the main pump unit.
• A rubber gasket for a secure seal.
• Two polythene connectors.
• Eight stainless steel hose clips for securing the high-pressure polythene piping.
