Injector Jet Kit 570 suit 125D

The Davey Injector Jet Kit 570 (Product Code: 22570) is a specific deep-well conversion kit for the Davey 125D pressure pump, designed to allow the system to draw water from greater depths and specifically for use in 5-inch bores. It is an essential component for high-pressure water supply from deep bores, tank filling, stock watering, and sprinkler supply.

Key Features

Deep Well Performance: This specific kit is designed to effectively draw water from depths down to 36 metres when paired with the 125D pump.

• Optimal Flow: With the 570 injector installed, the pump system can achieve a maximum flow rate of up to 87 litres per minute (lpm), depending on the specific depth and operating conditions.
• Bore Compatibility: The kit is sized for use in bores with a minimum internal diameter of 5 inches (125mm), as opposed to the 472 and 473 kits which suit 4-inch bores.
• Corrosion Resistance: The associated Davey 125D pump body is made from marine-grade aluminium with a Rilsan® lining, providing outstanding resistance to aggressive water and a long, low-maintenance life.

• A complete deep well injector kit includes all the necessary components for installation in a bore:
• A bronze injector and foot valve assembly that are lowered into the water.
• An adaptor flange (or bend) to connect the suction pipes to the pump head.
• A rubber gasket.
• Two polythene connectors.
• Eight stainless steel hose clips.
